Can be directly bent and stamped PPGI/PPGL Steel Coil

Can be directly bent and stamped PPGI/PPGL Steel Coil
PPGI/PPGL Steel Coil (color-coated steel coil) is a composite material that is coated with multiple layers of high-performance organic coatings on a galvanized (GI) or galvanized aluminum (GL) substrate after surface pretreatment. It combines the strength of the metal substrate with the decorative and protective properties of the coating. Its surface can be customized in a variety of colors and textures, and has excellent weather resistance, corrosion resistance and processability. It is widely used in areas such as building curtain walls, home appliance housings, and interior decoration that require high aesthetics and durability. It is an upgraded solution for traditional galvanized coils.
Phone : +8615852635738
Email : sale@tianguansteel.com
Wechat : +8615852635738
Whatsapp : +8615852635738
Product Description

PPGI/PPGL Steel Coil (color-coated steel coil) is a high-performance composite material processed by continuous roller coating on galvanized (GI) or galvanized (GL) substrates. Its core advantage lies in the perfect combination of the strength of the metal substrate and the versatility of the organic coating: the galvanized layer provides cathodic protection to prevent corrosion of the substrate, while the multi-layer coating on the surface (primer, topcoat and backcoat) gives the product a rich color selection (standard RAL color card or customized color matching), excellent weather resistance (PVDF coating can resist harsh environments such as ultraviolet rays and acid rain) and special surface texture (such as imitation wood grain, metal brushing, etc.).


Color-coated steel coils can be divided into different series such as polyester (PE), silicon-modified polyester (SMP), fluorocarbon (PVDF) according to the coating type. Among them, PVDF coating products are particularly suitable for high-end building curtain walls and roofs that are exposed to the outdoors for a long time. Compared with ordinary galvanized coils, PPGI/PPGL has a longer service life (up to 20-30 years for construction) and lower maintenance costs, while meeting environmental protection requirements (chromium-free pretreatment process). Modern color coating technology can also achieve special functions such as self-cleaning, heat insulation, and antibacterial, making it a popular green building material in industrial and civil fields.


Product NamePPGI (Prepainted Galvanized) / PPGL (Prepainted Galvalume) Steel Coil
TypePolyester (PE), Siliconized Polyester (SMP), PVDF (Fluorocarbon) Coated
Thickness0.2mm - 1.5mm (±0.03mm Precision)
Width600mm - 1250mm (Max 1500mm Custom)
LengthCustomized (Typical Coil Weight: 3-10 MT)
StandardASTM A755 / EN 10169 / JIS G3312
Surface FinishGlossy/Matte, Embossed (Woodgrain, Stone), Printed
ApplicationBuilding Roofing/Walls, Appliances, Furniture, Partition
CertificationISO 9001, AAMA 2605, LEED Compliant
TechniqueContinuous Coil Coating Process
EdgeMill Edge / Slit Edge (Burr-Free)
QualityNo Peeling, Color Uniformity (ΔE≤1.0), T-Bend Test ≤2T
Grade (ASTM UNS)G90/Z275 Base + Coating Type
Grade (EN)DX51D+AZ / DX54D+AZ with Coating Class
Main MarketNorth America, EU, Middle East, Southeast Asia
Brand NameTISCO
Delivery Time30-50 Days (Stock: 15-25 Days)
Port of LoadingShanghai/Tianjin/Qingdao (China), or specify
Price TermsFOB, CIF, CFR (Incoterms 2020)
Export PackingWaterproof Wrapping + Edge Protectors + Steel Frame
Supply Ability5,000 MT/Month (Standard Colors)
Payment Terms30% Deposit + 70% Against B/L Copy
